Keywords:SONL217-517 housing for 22217 bearing,SONL217-517 SONL plummer block housing
SONL217-517 bearing housing is SONL plummer block housings,it enable the bearings to achieve maximum bearing service life with less need for maintenance,this supports user efforts to further reduce mainenace costs, SONL217-517 Bearing housing(SONL Plummer block housings) are specially designed for oil lubrications,they can accommodate high temperature and bearings operating at high speed,it can easy alignment and handing during installation. SONL217-517 bearing housing are made of Grey cast iron or spheroidal graphite cast iron,SONL plummer block housings consist of a cap and base,they have four holes cast into the base for attachment bolts and primarily intended for 22217 E bearing with a H317 Adapter sleeve,the shaft of SONL217-517 plummer block housing is 75mm,and the height is 230mm,length is 330mm,the weight of SONL217-517 housing is 26kg,the SONL plummer block housings are not only working with 22217E bearings.But also 2217K self-aligning ball bearings,C2217K Carb toroidal roller bearings.
Application of SONL217-517 Bearing housings:
* Fans
* Flywheel
* Mining and construction
* Metallurgical
* Pulp and paper machine
* Emergency power generators
Advantage of SONL217-517 split Plummer block housings:
* Long service life
* Robust design
* Long relubrication intervals
* Ready for relubrication
* Condition monitoring facilities
* Avoid risk of mixed caps
* Fast and easy mounting and dismounting
XRB as the biggest Plummer block housing supplier and China bearing manufacturer,it can supply the best solution for plummer block housing and the bearings according to their specific applications.,it can supply Original SONL217-517 Bearing housing and 22217E Bearing, 2217K Bearing,C2217K Bearing,Our large quantity SONL217-517 plummer block housings Stock can meet your need with lowest price and fast delivery
Designation of SONL plummer block housing
suffix:
SONL :Plummer (Pillow ) block housing for oil lubrication
RA :Housing for CARB toroidal roller and self-aligning ball bearings when using a circulating oil lubrication system
A :Seal kit for shaft end
/VZ643 : Seal kit for bearings on a cylindrical seat and a plain shaft
/V51 :Signifies spare parts
MB :Oil pick up ring -brass(replacement for standard)
FRB: Locating ring for bearing housing
We accepted DHL,FEDEX,TNT express for small order and samples order,also the transportation By AIR or By Sea,by Train are all avaiable.we are sure we can ship our SONL217-517 bearing housing to your office at the first time.More technical details,please contact with :
E-mail: brandbearings@gmail.com, Skype:brandbearings
