Item:
CARB toroidal roller bearings(1)
Price:
Contact with XRB

Details

CARB toroidal roller bearings combine the self-aligning capability of spherical roller bearings with the axial displacement ability of cylindrical roller bearings. CARB bearings can also have the compact cross section and high load carrying capacity normally associated with needle roller bearings.
CARB bearings are intended exclusively as non-locating bearings. They can simplify the bearing arrangement design for shafts that are subjected to thermal expansion/contraction because axial displacement is accommodated within the bearing, virtually without friction. Bearing systems consisting of a spherical roller bearing in the locating position and a CARB bearing in the non-locating positionprovide a space and weight-saving bearing system with a low cost of ownership. CARB bearings can reduce noise and vibration levels, e.g. in paper machines and fans. CARB bearings are single row bearings with long, slightly barrel-shaped symmetrical rollers.
The outer ring has a torus-shaped raceway with a profile radius extending beyond the centre of the bearing. The inner ring raceway is shaped accordingly. The rollers of CARB bearings are self-guiding, i.e. they always adopt the position where the load is favourably distributed over the roller length, irrespective of whether the bearing rings are misaligned or axially displaced. The ability to distribute loads favourably keeps the friction and friction-generated heat at low level. Lower operating temperature extends the service life of the lubricant and the bearing.

bearing designation	bearing size (mm)
ã	inner	outer	width
C 3024 K	120	180	46
C 3024 KV	120	180	46
C 3024 V	120	180	46
C 4024 K30V	120	180	60
C 4024 V	120	180	60
C 4124 K30V	120	200	80
C 4124 V	120	200	80
C 6910-2CS5V	50	72	40
C 6912-2CS5V	60	85	45
C 6912-2NSV	60	85	45
C 4013-2CS5V	65	100	35
C 6915-2CS5V	75	105	54
C 4015-2CS5V	75	115	40
C 5918-2CS5V	90	125	46
C 4020-2CS5V	100	150	50
C 5020-2CS5V	100	150	67
C 4120-2CS5V	100	165	65
C 4022-2CS5V	110	170	60
C 4122-2CS5V	110	180	69
C 4024-2CS5V	120	180	60
C 4124-2CS5V	120	200	80
C 4026-2CS5V	130	200	69
C 4126-2CS5V	130	210	80
C 4028-2CS5V	140	210	69
C 4128-2CS5V	140	225	85
C 4030-2CS5V	150	225	75
C 4032-2CS5V	160	240	80
C 2224	120	215	58
C 2224 K	120	215	58
C 3224	120	215	76
C 3224 K	120	215	76
C 3026	130	200	52
C 3026 K	130	200	52
C 4026	130	200	69
C 4026 K30	130	200	69
C 4026 K30V	130	200	69
C 4026 V	130	200	69
C 4126 K30V/VE240	130	210	80
C 4126 V/VE240	130	210	80
C 2226	130	230	64
C 2226 K	130	230	64
C 2326 K/VE240	130	280	93
C 2326/VE240	130	280	93
C 3028	140	210	53
C 3028 K	140	210	53
C 4028 K30V	140	210	69
C 4028 V	140	210	69
C 4128 K30V	140	225	85
C 4128 V	140	225	85
C 2228	140	250	68
C 2228 K	140	250	68
C 3030 KMB	150	225	56
C 3030 KV	150	225	56
C 3030 MB	150	225	56
C 3030 V	150	225	56
C 4030 K30V	150	225	75
C 4030 V	150	225	75
C 3130	150	250	80
C 3130 K	150	250	80
C 4130 K30V	150	250	100
C 4130 V	150	250	100
C 2230	150	270	73
C 2230 K	150	270	73
C 3032	160	240	60
C 3032 K	160	240	60
C 4032	160	240	80
C 4032 K30	160	240	80
C 4032 K30V	160	240	80
C 4032 V	160	240	80
C 3132 KMB	160	270	86
C 3132 MB	160	270	86
C 4132 K30V	160	270	109
C 4132 V	160	270	109
C 3232	160	290	104
C 3232 K	160	290	104
C 3034	170	260	67
C 3034 K	170	260	67
C 4034 K30V	170	260	90
C 4034 V	170	260	90
C 3134	170	280	88
C 3134 K	170	280	88
C 4134 K30V	170	280	109
C 4134 V	170	280	109
C 2234	170	310	86
C 2234 K	170	310	86
C 3036	180	280	74
C 3036 K	180	280	74
C 3036 K/HA3C4	180	280	74
C 4036 K30V	180	280	100
C 4036 V	180	280	100
C 3136	180	300	96
C 3136 K	180	300	96
C 3136 K/HA3C4	180	300	96
C 4136 K30V	180	300	118
C 4136 V	180	300	118
C 3236	180	320	112
C 3236 K	180	320	112
C 3038	190	290	75

XRB bearing can produce CARB toroidal roller bearings,all of XRB CARB toroidal roller bearings are made of chrome steel, each CARB toroidal roller bearings must be 100% testing before Packing, CARB toroidal roller bearings are the same quality with NSK,NTN,TIMKEN,SNR bearings. CARB toroidal roller bearings are popular size that could be used in many applications,
if you have demand for spherical roller bearings,please contact with us.
