NNF5034ADA-2LSV Bearing

Inquire Add to Basket

  • NNF5034ADA-2LSV

  • Bearing NNF5034ADA-2LSV price

Keywords:NNF5034ADA-2LSV bearing,NNF5034ADA-2LSV Sealed double row full-complement cylindrical roller bearing

NNF5034ADA-2LSV bearing is sealed double row full-complement  Cylindrical roller bearing   and commonly type and widely used in many application which need very high capacity and load, it contains inner ring, outer ring but without cage,so this special design determine it can carry high capacity but low speed than the normal cylindrical roller bearing with cage,it can carry radial and axial loads in both directions.

NNF5034ADA-2LSV bearing suitable for high and middle high capacity,but low cost maintenance.EASIER as one of the biggest top quality bearing brand,Quality can be approved by the market.


NNF5034ADA-2LSV sealed double  row full-complement Cylindrical roller bearing

High capacity sealed full-complement Cylindrical roller bearing

NNF5034ADA2LSV  Bearing
170×260×122mm bearing
                NNF5034ADA-2LSV Bearing type cylindrical roller bearing
 inner diameter 170mm
outer diameter 260mm
width diameter 122mm
    NNF5034ADA-2LSV Cylindrical roller  bearing weight 22.5kg
bearing are available from many design, variants, series and size,

►Full complement cylindrical roller bearings have specially designed raceways and accommodate a large number of asymmetrical rollers.

►NNF5034ADA-2LSV bearing with brass cage can accommodate very heavy radial loads and very high speeds,

►NNF5034ADA-2LSV cylindrical roller bearing have two flange on either  the inner or outer ring to guide the rollers,this type of bearing have "open" flange, together with the roller end design and surface finish,so it can promote the formation of a lubricant film to reduce friction and frictional heat

►Cylindrical roller bearing have many kinds of design for inner ring and outer ring,with flange or without flange, with brass cage & steel cage & nylon cage, normal rollers or larger rollers.
Full-complement cylindrical roller bearings.		 Design:
full complement cylindrical roller bearing
NNF5034ADA-2LSV
►Metarial:High quality chrome steel
►Lubrication:Oil or grease
►dynamic load rating:512kN
►static load rating:1060kN
►Fatigue load limit:110kN
►Reference speed:0r/min
►limiting speed:530r/min
NNF5034ADA-2LSV bearing are widely used in industry area: ►Power generation
►Aggregate processing
►Oil fields&Pumps
►Crop shears
►Rolling mills
►Gear drives &Hoists
►Mining & construction










































XRB is the NNF5034ADA-2LSV bearing exporter & supplier,it can supply NNF5034ADA-2LSV bearing, Our large quantity sealed double row full complement Cylindrical roller bearing Stock can meet your need with lowest price and fast delivery.

Also you can find NNF5034ADA-2LSV Bearing, the other type and brand cylindrical roller bearing ：

Full complement cylindrical roller bearing
NN double row cylindrical roller bearing
NNU double row cylindrical roller bearing
SL Full-complement cylindrical roller bearing

We accepted DHL,FEDEX,TNT express for small order and samples order,also the transportation By Air or By Sea,by Train are all avaiable.we asure we can ship high quality NNF5034ADA-2LSV bearing to your office at the first time.more price and drawing of the bearings,please contact with our sales team.
