Keywords:FNL512A Flanged housing,FNL512A Flanged housing + 1212EKTN9 Bearing
FNL512A Flanged housing are made of Grey cast iron,it working with 22212CCK/W33 Bearing ,1212EKTN9 Bearing,2212EKTN9 Bearing,and C2212 KTN9 Bearing on an adapter sleeve ,FNL512A Flanged housing are non-split housings that are produced in two designs depending on size,smaller sizes up to and including size 13 have a triangular flange,larger size have a square flange.FNL housing are supplied with a cover either for shaft end or for throuth shafts,the housings with a cover for shaft ends have the designation suffix A,The housings with a cover for through shafts have the designation suffix B. FNL512A flanged housing is easy installation,this flanged housing available on the market are mainly Have the plummer block housing design working with sealed spherical roller bearings,Spherical roller bearing,carb toroidal roller bearing and self-aligning ball bearing,FNL512A Flanged housing is widely used in many industrial application, the shaft of FNL512A Flanged housing is 50mm, the height is 189mm, length is 210mm.,the weight of FNL512A Flanged housing is 5.2kg,
FNL512A Flanged housing enable the bearings to achieve maximum bearing service life with less need for maintenance .As one of the biggest China bearing manufacturer can supply the best solution for our Split plummer block housing customers according to their specific applications.
Applications of FNL512A Flanged housing
*Material handing
*Handing system
*Mining and construction
*Fluid machinery
*Metaillurgical
*Pulp and paper
Designation system for FNL512A Flanged housing
FNL Flanged housing
5(00)Housing for bearings on an adapter sleeve,diamter series 2
A Housing for shaft end with end cover
B Housing for through shaft
P Housing with machined recess for guide ring
V Housing with grease escape hole in the houing cover
TFL Double-lip seal for FNL Flanged housings
Material Of Split plummer block housing
As the experienced China bearing manufacturer & factory & exporter & supplier ,it can supply Original FNL512A Flanged housing, Our large quantity FNL512A Flanged housing Stock can meet your need for quality wth lowest price and fast delivery.We accepted DHL, FEDEX,TNT express for small order and samples order,also the transportation By AIR or By Sea,by Train are all avaiable.we are sure we can ship FNL512A Flanged housing to your office at the first time.More technical details,please contact with :
E-mail: brandbearings@gmail.com, Skype:brandbearings
