Item:
spherical roller bearings(4)
Price:
Contact with XRB

Details

Spherical roller bearings have two rows of rollers, a common sphered outer ring raceway and two inner ring raceways inclined at an angle to the bearing axis. The centre point of the sphere in the outer ring raceway is at the bearing axis. Therefore, the bearings are self-aligning and insensitive to misalignment of the shaft relative to the housing, which can be caused, for example, by shaft deflection. Spherical roller bearings are designed to accommodate heavy radial loads, as well as heavy axial loads in both directions.
Bearing performance is not only determined by load or speed ratings. There are a number of other factors that contribute to bearing performance. To a large extent, performance is influenced by the geometry of the rollers, raceways and cages, the heat treatment, as well as the surface finish of all contact surfaces.

23280 CAK/W33	400	720	256
22380 CA/W33	400	820	243
22380 CAK/W33	400	820	243
23984 CC/W33	420	560	106
23984 CCK/W33	420	560	106
23084 CA/W33	420	620	150
23084 CAK/W33	420	620	150
24084 ECA/W33	420	620	200
24084 ECAK30/W33	420	620	200
23184 CJ/W33	420	700	224
23184 CKJ/W33	420	700	224
24184 ECA/W33	420	700	280
24184 ECAK30/W33	420	700	280
23284 CA/W33	420	760	272
23284 CAK/W33	420	760	272
23988 CC/W33	440	600	118
23988 CCK/W33	440	600	118
23088 CA/W33	440	650	157
23088 CAK/W33	440	650	157
24088 ECA/W33	440	650	212
24088 ECAK30/W33	440	650	212
23188 CA/W33	440	720	226
23188 CAK/W33	440	720	226
24188 ECA/W33	440	720	280
24188 ECAK30/W33	440	720	280
23288 CA/W33	440	790	280
23288 CAK/W33	440	790	280
24892 CAMA/W20	460	580	118
24892 CAK30MA/W20	460	580	118
23992 CA/W33	460	620	118
23092 CA/W33	460	680	163
23092 CAK/W33	460	680	163
24092 ECA/W33	460	680	218
24092 ECAK30/W33	460	680	218
23192 CA/W33	460	760	240
23192 CAK/W33	460	760	240
24192 ECA/W33	460	760	300
24192 ECAK30/W33	460	760	300
23292 CAK/W33	460	830	296
23292 CAK/W33	460	830	296
23996 CA/W33	480	650	128
23996 CAK/W33	480	650	128
23096 CA/W33	480	700	165
23096 CAK/W33	480	700	165
24096 ECA/W33	480	700	218
24096 ECAK30/W33	480	700	218
23196 CA/W33	480	790	248
23196 CAK/W33	480	790	248
24196 ECA/W33	480	790	308
24196 ECAK30/W33	480	790	308
23296 CA/W33	480	870	310
23296 CAK/W33	480	870	310
239/500 CA/W33	500	670	128
239/500 CAK/W33	500	670	128
230/500 CA/W33	500	720	167
230/500 CAK/W33	500	720	167
240/500 ECA/W33	500	720	218
240/500 ECAK30/W33	500	720	218
231/500 CA/W33	500	830	264
231/500 CAK/W33	500	830	264
241/500 ECA/W33	500	830	325
241/500 ECAK30/W33	500	830	325
232/500 CA/W33	500	920	336
232/500 CAK/W33	500	920	336
248/530 CAMA/W20	530	650	118
248/530 CAK30MA/W20	530	650	118
239/530 CA/W33	530	710	136
239/530 CAK/W33	530	710	136
230/530 CA/W33	530	780	185
230/530 CAK/W33	530	780	185
240/530 ECA/W33	530	780	250
240/530 ECAK30/W33	530	780	250
231/530 CAK/W33	530	870	272
241/530 ECA/W33	530	870	335
241/530 ECAK30/W33	530	870	335
232/530 CA/W33	530	980	355
232/530 CAK/W33	530	980	355
239/560 CA/W33	560	750	140
239/560 CAK/W33	560	750	140
230/560 CA/W33	560	820	195
230/560 CAK/W33	560	820	195
240/560 ECA/W33	560	820	258
240/560 ECAK30/W33	560	820	258
231/560 CA/W33	560	920	280
231/560 CAK/W33	560	920	280
241/560 ECJ/W33	560	920	355
241/560 ECK30J/W33	560	920	355
232/560 CA/W33	560	1030	365
232/560 CAK/W33	560	1030	365
239/600 CA/W33	600	800	150
239/600 CAK/W33	600	800	150
230/600 CA/W33	600	870	200
230/600 CAK/W33	600	870	200
240/600 ECAF/W33	600	870	272
240/600 ECAK30F/W33	600	870	272
231/600 CA/W33	600	980	300
231/600 CAK/W33	600	980	300
241/600 ECA/W33	600	980	375
241/600 ECAK30/W33	600	980	375
232/600 CA/W33	600	1090	388
232/600 CAK/W33	600	1090	388
238/630 CAMA/W20	630	780	112
238/630 CAKMA/W20	630	780	112
239/630 CA/W33	630	850	165
239/630 CAK/W33	630	850	165
230/630 CA/W33	630	920	212
230/630 CAK/W33	630	920	212
240/630 ECJ/W33	630	920	290
240/630 ECK30J/W33	630	920	290
231/630 CA/W33	630	1030	315
231/630 CAK/W33	630	1030	315
241/630 ECA/W33	630	1030	400
241/630 ECAK30/W33	630	1030	400
238/670 CAMA/W20	670	820	113
238/670 CAKMA/W20	670	820	113
248/670 CAMA/W20	670	820	150
239/670 CA/W33	670	900	170
239/670 CAK/W33	670	900	170
230/670 CA/W33	670	980	230
230/670 CAK/W33	670	980	230
240/670 ECA/W33	670	980	308
240/670 ECAK30/W33	670	980	308
231/670 CA/W33	670	1090	336
231/670 CAK/W33	670	1090	336
241/670 ECA/W33	670	1090	412
241/670 ECAK30/W33	670	1090	412
232/670 CA/W33	670	1220	438
232/670 CAK/W33	670	1220	438
238/710 CAMA/W20	710	870	118
239/710 CA/W33	710	950	180
239/710 CAK/W33	710	950	180
249/710 CA/W33	710	950	243
249/710 CAK/W33	710	950	243
230/710 CA/W33	710	1030	236
230/710 CAK/W33	710	1030	236
240/710 ECA/W33	710	1030	315
240/710 ECAK30/W33	710	1030	315
231/710 CA/W33	710	1150	345
231/710 CAK/W33	710	1150	345
241/710 ECA/W33	710	1150	438
241/710 ECAK30/W33	710	1150	438
232/710 CA/W33	710	1280	450
232/710 CAK/W33	710	1280	450
238/750 CAMA/W20	750	920	128
238/750 CAKMA/W20	750	920	128
239/750 CA/W33	750	1000	185
239/750 CAK/W33	750	1000	185
249/750 CA/W33	750	1000	250
249/750 CAK30/W33	750	1000	250
230/750 CA/W33	750	1090	250
230/750 CAK/W33	750	1090	250
240/750 ECA/W33	750	1090	335
240/750 ECAK30/W33	750	1090	335
231/750 CA/W33	750	1220	365
231/750 CAK/W33	750	1220	365
241/750 ECA/W33	750	1220	475
241/750 ECAK30/W33	750	1220	475
232/750 CAF/W33	750	1360	475
232/750 CAKF/W33	750	1360	475
248/800 CAMA/W20	800	980	180
248/800 CAK30MA/W20	800	980	180
239/800 CA/W33	800	1060	195
239/800 CAK/W33	800	1060	195
249/800 CA/W33	800	1060	258
249/800 CAK30/W33	800	1060	258
230/800 CA/W33	800	1150	258
230/800 CAK/W33	800	1150	258
240/800 ECA/W33	800	1150	345
240/800 ECAK30/W33	800	1150	345
231/800 CA/W33	800	1280	375
231/800 CAK/W33	800	1280	375
241/800 ECA/W33	800	1280	475
241/800 ECAK30/W33	800	1280	475
238/850 CAMA/W20	850	1030	136
238/850 CAKMA/W20	850	1030	136
239/850 CA/W33	850	1120	200
239/850 CAK/W33	850	1120	200
249/850 CA/W33	850	1120	272
249/850 CAK30/W33	850	1120	272
230/850 CA/W33	850	1220	272
230/850 CAK/W33	850	1220	272
240/850 ECA/W33	850	1220	365
240/850 ECAK30/W33	850	1220	365
231/850 CA/W33	850	1360	400
231/850 CAK/W33	850	1360	400
241/850 ECAF/W33	850	1360	500
241/850 ECAK30F/W33	850	1360	500
248/900 CAMA/W20	900	1090	190
248/900 CAK30MA/W20	900	1090	190
239/900 CA/W33	900	1180	206
239/900 CAK/W33	900	1180	206
230/900 CA/W33	900	1280	280
230/900 CAK/W33	900	1280	280
240/900 ECA/W33	900	1280	375
240/900 ECAK30/W33	900	1280	375
241/900 ECAF/W33	900	1420	515
241/900 ECAK30F/W33	900	1420	515
239/950 CA/W33	950	1250	224
239/950 CAK/W33	950	1250	224
249/950 CA/W33	950	1250	300
249/950 CAK30/W33	950	1250	300
230/950 CA/W33	950	1360	300
230/950 CAK/W33	950	1360	300
240/950 CAF/W33	950	1360	412
240/950 CAK30F/W33	950	1360	412
241/950 ECAF/W33	950	1500	545
241/950 ECAK30F/W33	950	1500	545
238/1000 CAMA/W20	1000	1220	165
238/1000 CAKMA/W20	1000	1220	165
249/1000 CA/W33	1000	1320	315
249/1000 CAK30/W33	1000	1320	315
230/1000 CAF/W33	1000	1420	308
230/1000 CAKF/W33	1000	1420	308
240/1000 CAF/W33	1000	1420	412
240/1000 CAK30F/W33	1000	1420	412
231/1000 CAF/W33	1000	1580	462
231/1000 CAKF/W33	1000	1580	462
241/1000 ECAF/W33	1000	1580	580
241/1000 ECAK30F/W33	1000	1580	580
238/1060 CAMA/W20	1060	1280	165
238/1060 CAKMA/W20	1060	1280	165
248/1060 CAMA/W20	1060	1280	218
248/1060 CAK30MA/W20	1060	1280	218
239/1060 CAF/W33	1060	1400	250
239/1060 CAKF/W33	1060	1400	250
249/1060 CAF/W33	1060	1400	335
249/1060 CAK30F/W33	1060	1400	335
230/1060 CAF/W33	1060	1500	325
230/1060 CAKF/W33	1060	1500	325
240/1060 CAF/W33	1060	1500	438
240/1060 CAK30F/W33	1060	1500	438
248/1120 CAFA/W20	1120	1360	243
248/1120 CAK30FA/W20	1120	1360	243
249/1120 CAF/W33	1120	1460	335
249/1120 CAK30F/W33	1120	1460	335
240/1120 CAF/W33	1120	1580	462
240/1120 CAK30F/W33	1120	1580	462
238/1180 CAFA/W20	1180	1420	180
238/1180 CAKFA/W20	1180	1420	180
248/1180 CAFA/W20	1180	1420	243
248/1180 CAK30FA/W20	1180	1420	243
239/1180 CAF/W33	1180	1540	272
239/1180 CAKF/W33	1180	1540	272
249/1180 CAF/W33	1180	1540	355
249/1180 CAK30F/W33	1180	1540	355
230/1250 CAF/W33	1250	1750	375
230/1250 CAKF/W33	1250	1750	375
248/1320 CAFA/W20	1320	1600	280
248/1320 CAK30FA/W20	1320	1600	280
249/1320 CAF/W33	1320	1720	400
249/1320 CAK30F/W33	1320	1720	400
248/1500 CAFA/W20	1500	1820	315
248/1500 CAK30FA/W20	1500	1820	315
248/1800 CAFA/W20	1800	2180	375
248/1800 CAK30FA/W20	1800	2180	375

XRB bearing can produce spherical roller bearings,all of XRB spherical roller bearings bearing are made of chrome steel, each spherical roller bearings must be 100% testing before Packing, spherical roller bearings are the same quality with NSK,NTN,TIMKEN,SNR bearings. spherical roller bearings are popular size that could be used in many applications,
if you have demand for spherical roller bearings,please contact with us.
