China SY7/8TF Bearing Insert

SY7/8TF - SKF Y-Bearing Plummer Block Unit - 22.225mm - Bore Size
YAR205-014-2F Insert bearing + Pillow block housing

E-mail: sales@xrbearing.com, brandbearings@gmail.com
Skype:brandbearings
Whatsapp: 0086-13280450757
www.xrbearing.com
Availability:
  • SY7/8TF
  • EASIER
  • YAR205-014-2F
  • SY7/8TF
  • USD$3-6

This SY7/8TF bearing is a Y-Bearing Plummer Block Unit with a bearing insert with grub screws, YAR2-2F series. The bearing's dimensions are 22.225mm Bore Size. Imperial,

Y-Bearings Plummer Block Unit, Cast Housing

Weight:0.8kg


SY7/8TF bearing plummer block units with a cast housing and grub screws, with a standard inner ring, is an insert single deep groove ball bearings with a convex sphered outside diameter and working together with a housing,SY7/8TF plummer block unit consist of SY505U Housing and YAR205-014-2F Bearing, SY7/8TF bearing plummer block unit can accommodate moderate initial misalignment,SY7/8TF bearings is widely used in many industrial application, the inner diameter is 22.225mm, the outer ring is 70mm,the height is 34.1mm, the weight of SY7/8TF bearings is 0.81kgSY7/8TF bearings with a standard inner ring are designed in according with a moduar concept,each SY7/8TF bearing can be fitted with pillow block housing of various diameter and width series if they have correct outside diameter for the housing. XRB as one of the biggest China bearing manufacturer can supply the best solution for our Y-housing customers according to their specific applications.


Pillow block bearing is mainly used to bear the combined radial and axial load, which is mainly the radial load. Generally, it is not suitable to bear the axial load alone. This type of bearing can be installed with an inner ring (with a full set of rollers and retainers) and an outer ring. This kind of bearing does not allow the shaft to be tilted relative to the housing, and additional axial force will be generated when the radial load is used. The size of the axial clearance of this kind of bearing has a great influence on whether the bearing can work normally. When the axial clearance is too small, the temperature rise is higher; when the axial clearance is large, the bearing is easy to be damaged. Therefore, special attention should be paid to adjusting the axial clearance of the bearing during installation and operation. If necessary, pre-interference installation can be used to increase the rigidity of the bearing.


XRB as the experienced China bearing manufacturer  & factory & exporter & supplier, it can supply Original SY7/8TF bearings, Our large quantity SY7/8TF bearings Stock can meet your need with lowest price and fast delivery.

We accepted DHL, FEDEX, TNT express for small order and samples order, also the transportation By AIR or By Sea, by Train are all avaiable. we are sure we can ship our SY7/8TF bearings to your office at the first time.More technical details,please contact with:
