SY1.5/8TF bearing unit

SY1.5/8TF - Y-Bearing Plummer Block Unit - 41.275mm - Bore Size

SY508U Housing and YAR209-110-2F Bearing

Weight: 2.45kg

SY1.5/8TF bearing plummer block units with a cast housing and grub screws, with a standard inner ring, is an insert single deep groove ball bearings with a convex sphered outside diameter and working together with a housing, SY1.5/8TF plummer block unit consist of SY508U Housing and YAR209-110-2F Bearing, SY1.5/8TF bearing plummer block unit can accommodate moderate initial misalignment, SY1.5/8TF bearings is widely used in many industrial application, the inner diameter is 41.275mm, the outer ring is 107mm,the height is 49.2mm, the weight of SY1.5/8TF bearings is 2.45kg.

SY1.5/8TF bearings with a standard inner ring are designed in according with a moduar concept, each SY1.5/8TF bearing can be fitted with pillow block housing of various diameter and width series if they have correct outside diameter for the housing. XRB as one of the biggest China bearing manufacturer can supply the best solution for our Y-housing customers according to their specific applications.

Pillow Block Bearing Units

Thick Pillow Block Units

Tapped-Base Pillow Block Units

High-Base Pillow Block Units

Narrow Inner Ring Bearing Pillow Block Units

Light Pillow Block Units

Compact Pillow Block Units

Corrosion Resistant Series Pillow Block Units
