China pillow block bearing unit UCP201

  • Bearing UCP201

  • bearing UCP201 price

Pillow Block Bearing UCP201
Bearing specification
Housing Number P203
Insert Bearing number UC201
Shaft Size: 12mm
Bolt Size M10 3/8 in
H 30.2mm
L 127mm
A 38mm
J 95mm
weight 0.63kg
Locking style Set Screw Locking
Grease Fitting A-1/4-28UNF

High Quality Pillow Block Bearing UCP201 consist of Cast Iron Housing(Pillow type), ball ,cage,wide inner ring,Hexagon soket set scrow,outer ring with spherical outside serface ,Seal,Grease hole,slinger ect.  you can see that this bearing have a wide inner ring with set screws for attaching to the shaft,housing is cast iron with a grease zerk for re-lubrication the bearing.

The UCP201 pillow block set screws are placed at a 90-degree angle to optimize balance between holding power and inner ring distortion. The UCP201-08 pillow block bearings are relubricatable and offer a full-width inner ring for added stability.

The UCP201 pillow block bearing features a positive-contact, three-pieces, fiber-imbedded R-seal to protect against harmfull contaminants and retain lubricant. The setscrew locking mechanism on the pillow block bearing is easy to install and well suited for reversing applications and normal loads.
Applications for the UCP201 pillow block bearing include: Construction, Conveyors, Food and Beverage, Packaging and General Industrial Equipment.


AMI: UCP 201
Browning: VPS-208
Dodge: P2B-SC-008
Link-Belt: P3-U208N
Link-Belt: P3-Y208N
NSK: USP201-08S
NTN: UCP202-010T
Peer: FHSP201G
Sealmaster: NP-08

XRB bearing is the China Bearing manufacturer & exporter & factory & supplier, Pillow Block Bearing also name insert bearing with housing,it can produce pillow block bearing unit with cast iron housing, pressed steel housing,stainless steel housing. and many kinds of Pillow Block Bearing unit like UCP200 Series,UCPX00 Series,HCAK200 Series, UEP200 Series,SBSP200 Series,SSUCP200 Series,SSUCP200-TP Series,TYPE-E Series, M2000 Series,BLP200 Series, ALP200 Series,UCPH200 Series, UCPA200 Series. we are sure we can supply the good price ,fast delivery and perfect service for all of the bearing distributor and end user.
