SYJ1.1/4TF Bearing Unit

SYJ 1.1/4 TF Pillow block ball bearing units with Cast iron Housing

SYJ 507 pillow block + YAR 207-104-2F bearing

Weight: 1.5kg

SYJ1.1/4TF bearing plummer block units with a cast housing and grub screws, with a standard inner ring, is an insert single deep groove ball bearings with a convex sphered outside diameter and working together with a housing, SYJ1.1/4TF plummer block unit consist of SYJ507 Housing and YAR207-104-2F Bearing, SYJ1.1/4TF bearing plummer block unit can accommodate moderate initial misalignment, SYJ1.1/4TF bearings is widely used in many industrial application, the inner diameter is 31.75mm, the outer ring is 93mm, the height is 42.9mm, the weight of SY1.1/4TF bearings is 1.5kg.

SYJ1.1/4TF bearings with a standard inner ring are designed in according with a moduar concept, each SYJ1.1/4TF bearing can be fitted with pillow block housing of various diameter and width series if they have correct outside diameter for the housing. XRB as one of the biggest China bearing manufacturer can supply the best solution for our Y-housing customers according to their specific applications.

Pillow Block Ball Bearing Units interchange with many different models and can be bolted to machinery without any modification. The exact amount of clearance is allowed between the bore and the shaft to allow a perfect fit. Therefore, FYH Ball Bearing Units do not require any

additional lubrication or seal installation. As a result, handling and downtime can be drastically reduced. Four different locking mechanisms are available:

(1) Set Screw

(2) Eccentric Locking Collar

(3) Tapered Adapter

(4) Concentric Collar
