bearing NUP204 ECP
bearing NUP204 ECP bearing
High precision Cylindrical roller bearing | NUP204 ECP Bearing, 20×47×14mm bearing |
NUP204 ECP Bearing type | cylindrical roller bearing |
roller bearing inner diameter | 20mm |
roller bearing outer diameter | 47mm |
roller bearing width diameter | 14mm |
NUP204 ECP Cylindrical roller bearing weight | 0.11kg |
bearing are available from many design, variants, series and size, ► NUP204 ECP cylindrical roller bearings have specially designed raceways and accommodate a large number of asymmetrical rollers. ► NUP204 ECP bearing with a cage can accommodate very heavy radial loads and very high speeds, ► NUP204 ECP cylindrical roller bearing have two flange on either the inner or outer ring to guide the rollers,this type of bearing have "open" flange, together with the roller end design and surface finish,so it can promote the formation of a lubricant film to reduce friction and frictional heat ►cylindrical roller bearing have many kinds of design for inner ring and outer ring,with flange or without flange, with brass cage & steel cage & nylon cage, normal rollers or larger rollers. | Design: cylindrical roller bearing NUP204 ECP |
►Metarial:High quality chrome steel ►Lubrication:Oil or grease ►sealed:Rubber sealed or press steel shielded ►dynamic load rating: 25.1kN ►static load rating:22kN ►Fatigue load limit:2.75kN ►Reference speed:16000r/min ►limiting speed: 19000r/min | |
NUP204 ECP bearing are widely used in industry area: | ►Power generation ►Aggregate processing ►Oil fields&Pumps ►Crop shears ►Rolling mills ►Gear drives &Hoists ►Mining & construction |
