Model:
KF100AR0
Brand:
TKW
Item:
thin section bearing

Product Description

KF100AR0

This diagram only shows the lengths d, D, B, and H in millimeters.

KF100AR0.PDF

The document contains charts in millimeters, as well as a brief introduction to our factory

Download

Technical information.

Metric

lmperial

KF100AR0 Thin Section Bearing
d	10in	aperture
D	11.5in	outer diameter
H	0.75in	Radial cross-section
B	0.75in	width
d1	≈10.555in	Inner ring rib diameter
D1	≈10.945in	Outer ring flange diameter
D4	≈11.106in	Outer ring flange diameter
	0.375in	Ball diameter
	0.08in	Maximum chamfer radius of shaft or bearing

KF100AR0 Thin Section Bearing
d	254mm	aperture
D	292.1mm	outer diameter
H	19.05mm	Radial cross-section
B	19.05mm	width
d1	≈268.097mm	Inner ring rib diameter
D1	≈278.003mm	Outer ring flange diameter
D4	≈282.092mm	Outer ring flange diameter
	9.525mm	Ball diameter
	2.032mm	Maximum chamfer radius of shaft or bearing

If you have any questions, please feel free to email us!

The TKW Bearing part series KF100AR0 is a potential replacement for these common bearing part numbers.

KAYDON	RBC	INA	SSB	SILVER	NSK
KF100AR0	KF100AR0*RBC	CSEF100	RF100AR0	SF100AR0	-

TKW is a manufacturer specializing in high-precision bearings. Its product portfolio includes high-precision hybrid ceramic ball bearings, ultra-thin-section bearings, servo motor bearings, high-precision stainless steel bearings, vacuum pump bearings, magnetic levitation bearings, thin-section crossed roller bearings, reactor bearings, full ceramic bearings, bearings for the food and beverage industry, new energy vehicle bearings, excavator bearings, construction machinery bearings, and custom-engineered bearings. The products meet P5, P4, and P2 precision standards, and customized services are available to meet specific customer requirements.
