Stainless Steel Bearing

- Stainless steel pillow block bearing with pillow block
- Stainless steel deep groove ball bearing
- Stainless Steel Linear Guide Way
- Stainless steel self aligning ball bearing
- Stainless steel spherical roller bearing
- Stainless steel angular contact ball bearing
- Stainless steel tapered roller bearing
- Stainless steel thrust ball bearing
- Stainless steel Ceramic hybrid bearing
- Engineering plastic bearing with housing
- Stainless steel rod end bearing

E-mail: sales@xrbearing.com, brandbearings@gmail.com
Skype:brandbearings
Whatsapp: 0086-13280450757
www.xrbearing.com
Availability:

Stainless steel bearing

Compared with ordinary chrome steel bearings, stainless steel bearings not only have obvious advantages in material, but also have much stricter control on process and precision than ordinary chrome steel bearings. During the working process, the stainless steel bearing works stably, with low noise, corrosion resistance and wide application.



AISI SUS440C stainless steel (domestic brand: 9Cr18Mo, 9Cr18) is used for bearing ring and rolling element material after vacuum quenching and tempering. The cage and sealing ring frame material is AISI304 stainless steel (domestic brand: OCr18Ni9). Compared with ordinary bearing steel, stainless steel bearings have stronger anti-rust and anti-corrosion properties. Choose suitable lubricants, dust caps, etc., and can be used in an environment of -60℃~+300℃. Stainless steel bearings can resist corrosion caused by moisture and several other media.



stainless steel bearings-1


This type of stainless steel bearing is the same as the standard chrome steel bearing made of carbon chromium (rolling bearing) steel. It has a bearing raceway groove and a high degree of fit between the bearing raceway and the ball.



Because of its high mechanical strength and load capacity, stainless steel bearings are widely used in medical equipment, pharmaceutical machinery, low temperature engineering, optical instruments, high-speed machine tools, high-speed motors, printing machinery, and food processing machinery.



Advantage of stainless steel bearings

1. Excellent corrosion resistance: stainless steel bearings are not easy to rust and have strong corrosion resistance.

2. Washable: stainless steel bearings can be washed without relubricating

3. Can operate in liquid condition: Due to the materials used, we can operate bearings and bearing seats in liquid

4. AISI 316 stainless steel does not require oil or grease for corrosion protection. Therefore, if the speed and load are low, there is no need for lubrication

5. Cleanness: stainless steel is naturally clean and does not corrode

6. High heat resistance: stainless steel bearings are equipped with high temperature polymer cages or cages without a complete complement structure, which can operate in a higher temperature range of 180°F to 1000°F. (Requires high temperature grease)





- Stainless steel pillow block bearing with pillow block

- Stainless steel deep groove ball bearing

- Stainless Steel Linear Guide Way

- Stainless steel self aligning ball bearing

- Stainless steel spherical roller bearing

- Stainless steel angular contact ball bearing

- Stainless steel tapered roller bearing

- Stainless steel thrust ball bearing

- Stainless steel Ceramic hybrid bearing

- Engineering plastic bearing with housing

- Stainless steel rod end bearing


The main benefit of EASIER stainless steel bearings is their resistance to corrosion in moist and other corrosive environments.

They are also very versatile since the sealed versions can be supplied with different greases as well as seals from different materials. This allows the choice of the most suitable grease for each application, for example, the use of food compatible, non- toxic bearing grease for the food industry.



Applications

stainless steel bearings are recommended for use wherever resistance to corrosion is desired. Typical industries include:

•  Food and beverage

•  Pharmaceutical

•  Chemical and hydrocarbon processing

•  Medical

•  Printing

•  Engines and pumps

•  Paper

•  Offshore

W 627/5-2ZW 637/8-2ZW 61701-2RS1WBB1-8714-2ZSW 617/5 RW 61700 RW 61704 R
W 627/5-2ZSW 637/8-2ZSW 61701-2ZSW 61704-2RS1W 627/5 R-2ZW 61700 XR-2RS1W 61704 R-2ZS
W 637/5 X-2ZWBB1-8708-2RS1W 61801-2RS1W 61704-2ZSW 627/5 R-2ZSW 61700 XR-2ZSW 61804 R
W 637/5 X-2ZSWBB1-8708-2ZW 61801-2ZW 61804-2RS1W 627/5 XRW 61800 RW 63804 R
WBB1-8705-2RS1W 618/8-2ZW 63801-2RS1W 61804-2ZW 637/5 XR-2ZW 63800 RW 61804 R-2Z
WBB1-8705-2ZW 628/8-2RS1W 63801-2ZW 63804-2RS1W 637/5 XR-2ZSW 61800 R-2RS1W 63804 R-2Z
W 628/5-2RS1W 628/8-2ZW 61901-2RS1W 63804-2ZWBB1-8705 RW 61800 R-2ZW 61904 R
W 628/5-2ZW 638/8-2ZW 61901-2ZW 61904-2RS1WBB1-8705 R-2RS1W 63800 R-2RS1W 61904 R-2Z
W 638/5-2RS1W 619/8-2RS1W 6001-2RS1W 61904-2ZWBB1-8705 R-2ZW 63800 R-2ZW 61705 R
W 638/5-2ZW 619/8-2ZW 6001-2RS1/VP311W 6004-2RS1W 618/5 RW 61900 RW 61805 R
W 619/5 X-2ZW 608-2RS1W 6001-2ZW 6004-2RS1/VP311W 628/5 R-2ZW 61900 R-2RS1W 63805 R
W 619/5-2RS1W 608-2RS1/VP311W 6201-2RS1W 6004-2ZW 638/5 R-2RS1W 61900 R-2ZW 61805 R-2Z
W 619/5-2ZW 608-2ZW 6201-2RS1/VP311W 6204-2RS1W 638/5 R-2ZW 61701 RW 63805 R-2Z
W 605-2RS1W 628-2RS1W 6201-2ZW 6204-2RS1/VP311W 619/5 RW 61701 R-2RS1W 61905 R
W 605-2ZW 628-2ZW 6301-2RS1W 6204-2ZW 619/5 R-2RS1W 61701 R-2ZSW 61905 R-2Z
W 625-2RS1W 638-2RS1W 6301-2ZW 6304-2RS1W 619/5 R-2ZW 61801 RW 61706 R
W 625-2ZW 638-2ZW 61702-2RS1W 6304-2ZW 605 RW 63801 RW 61806 R
W 635-2RS1W 637/9-2ZW 61702-2ZW 61705-2RS1W 605 R-2RS1W 61801 R-2ZSW 63806 R
W 635-2ZW 637/9-2ZSW 61802-2RS1W 61805-2RS1W 605 R-2ZW 63801 R-2ZW 61806 R-2Z
W 627/6-2ZW 628/9-2RS1W 61802-2ZW 61805-2ZW 625 RW 61901 RW 63806 R-2Z
WBB1-8706-2RS1W 628/9-2ZW 63802-2RS1W 63805-2RS1W 625 R-2RS1W 61901 R-2RS1W 61906 R
WBB1-8706-2ZW 638/9-2ZW 63802-2ZW 63805-2ZW 625 R-2ZW 61901 R-2ZW 61906 R-2Z
W 628/6-2RS1W 619/9-2RS1W 61902-2RS1W 61905-2RS1W 635 RW 61702 RW 61807 R
W 628/6-2ZW 619/9-2ZW 61902-2ZW 61905-2ZW 635 R-2RS1W 61702 R-2RS1W 61807 R-2Z
W 619/6-2RS1W 609-2RS1W 6002-2RS1W 6005-2RS1W 635 R-2ZW 61702 R-2ZW 61907 R
W 619/6-2ZW 609-2ZW 6002-2RS1/VP311W 6005-2RS1/VP311W 617/6 RW 61802 RW 61907 R-2Z
W 619/6 X-2RS1W 629-2RS1W 6002-2ZW 6005-2ZW 627/6 R-2ZW 63802 RW 61808 R
W 619/6 X-2ZW 629-2ZW 6202-2RS1W 6205-2RS1W 627/6 XRW 61802 R-2ZW 61808 R-2Z
W 606-2RS1W 639-2RS1W 6202-2RS1/VP311W 6205-2RS1/VP311WBB1-8706 R-2RS1W 63802 R-2ZW 61908 R
W 606-2ZW 639-2ZW 6202-2ZW 6205-2ZWBB1-8706 R-2ZW 61902 RW 61908 R-2Z
W 626-2RS1W 61700 X-2RS1W 6302-2RS1W 6305-2RS1W 618/6 RW 61902 R-2RS1W 61809 R
W 626-2ZW 61700 X-2ZSW 6302-2ZW 6305-2ZW 628/6 R-2RS1W 61902 R-2ZW 61809 R-2Z
W 636-2RS1W 61800-2RS1WBB1-8712-2ZSW 61806-2RS1W 628/6 R-2ZW 61703 RW 61909 R
W 636-2ZW 61800-2ZW 61703-2RS1W 61806-2ZW 619/6 RW 61703 R-2ZSW 61909 R-2Z
W 627/7-2ZSW 63800-2RS1W 61703-2ZW 63806-2RS1W 619/6 R-2RS1W 61803 RW 61810 R
WBB1-8707-2ZW 63800-2ZW 61803-2RS1W 63806-2ZW 619/6 R-2ZW 63803 RW 61810 R-2Z
W 628/7-2RS1W 61900-2RS1W 61803-2ZW 61906-2RS1W 606 RW 61803 R-2ZW 61910 R
W 628/7-2ZW 61900-2ZW 63803-2RS1W 61906-2ZW 606 R-2RS1W 63803 R-2ZW 61910 R-2Z
W 619/7-2RS1W 6000-2RS1W 63803-2ZW 6006-2RS1W 606 R-2ZW 61903 RWBB1-8708 R-2RS1
W 619/7-2ZW 6000-2RS1/VP311W 61903-2RS1W 6006-2RS1/VP311W 626 RW 61903 R-2ZWBB1-8708 R-2Z
W 607-2RS1W 6000-2ZW 61903-2ZW 6006-2ZW 626 R-2RS1W 61710-2RS1W 618/8 R
W 607-2ZW 6200-2RS1W 6003-2RS1W 6206-2RS1W 626 R-2ZW 61810-2RS1W 628/8 R-2RS1
W 627-2RS1W 6200-2RS1/VP311W 6003-2RS1/VP311W 6206-2RS1/VP311W 607 RW 61810-2ZW 628/8 R-2Z
W 627-2ZW 6200-2ZW 6003-2ZW 6206-2ZW 607 R-2RS1W 61910-2RS1W 638/8 R-2Z
W 637-2RS1W 6300-2RS1W 6203-2RS1W 6306-2RS1W 607 R-2ZW 61910-2ZW 619/8 R
W 637-2ZW 6300-2ZW 6203-2RS1/VP311W 6306-2ZW 627 RW 6010-2RS1W 619/8 R-2RS1

W 61908-2RS1W 6203-2ZW 61707-2RS1W 627 R-2ZW 6010-2ZW 619/8 R-2Z

W 61908-2ZW 6303-2RS1W 61807-2RS1W 617/8 RW 6210-2RS1W 608 R

W 61809-2RS1W 6303-2ZW 61807-2ZW 637/8 R-2ZW 6210-2ZW 608 R-2RS1

W 61809-2Z
W 61907-2RS1W 637/8 R-2ZSW 6009-2RS1W 608 R-2Z

W 61909-2RS1
W 61907-2ZW 637/8 XRW 6009-2Z

W 61909-2Z
W 6007-2RS1
W 6209-2RS1



W 6007-2RS1/VP311
W 6209-2Z



W 6007-2Z





W 6207-2RS1





W 6207-2RS1/VP311





W 6207-2Z





W 6307-2RS1





W 6307-2Z





W 61708-2RS1



Stainless Steel Rod Ends SPHS

SPHS20 Stainless Steel Rod Ends

Bearing No. Dimensions(mm)
Ball
dia
a
mis.
angle
Load ratings
(KN)
weight
Kg
H7
B C1 d1 d2 d3-6H h1 L3 (L4) L5 d4 d5 sw Dynamic Static
SPHS5 5 8 6 7.7 16 M5 27 11 35 4 9 11 9 11.11 13 2.5 6.6 0.016
SPHS6 6 9 6.75 8.9 18 M6 30 13 39 5 10 13 11 12.7 13 3.2 8.1 0.025
SPHS8 8 12 9 10.3 22 M8 36 16 47 5 12.5 16 14 15.87 14 5.4 12.6 0.043
SPHS10 10 14 10.5 12.9 26 M10 43 20 56 6.5 15 19 17 19.05 13 7.5 16.6 0.072
SPHS12 12 16 12 15.4 30 M12 50 23 65 6.5 17.5 22 19 22.22 13 10 22 0.107
SPHS14 14 19 13.5 16.8 34 M14 57 27 74 8 20 25 22 25.4 16 13 27.8 0.160
SPHS15 15 20 14 18.1 36 M14 61 30 79 8 21 26 22 26.98 16 14.5 29 0.186
SPHS16 16 21 15 19.3 38 M16 64 32 83 8 22 27 22 28.58 15 16 34.5 0.210
SPHS17 17 22 16 20.6 40 M16X1.5 67 34 87 10 24 31 27 30.16 14 18 36 0.259
SPHS18 18 23 16.5 21.8 42 M18X1.5 71 35 92 10 25 31 27 31.75 15 19.5 40.8 0.295
SPHS20 20 25 18 24.3 46 M20X1.5 77 39 100 10 27.5 34 30 34.92 14 23 46.5 0.380
SPHS22 22 28 20 25.8 50 M22x1.5 84 42 109 12 30 37 32 38.1 15 29 52.6 0.490
SPHS25 25 31 22 29.5 60 M24x2 94 48 124 12 33.5 42 36 42.86 15 40.5 74.1 0.750
SPHS28 28 35 24 32.29 66 M27x2 103 53 136 12 37 46 41 47.63 15 46.1 88.7 0.950
SPHS30 30 37 25 34.8 70 M30x2 110 56 145 15 40 50 41 50.8 17 54.3 94.0 1.130


Stainless Steel Rod Ends SPHS

SPHS20 Stainless Steel Rod Ends

Bearing No. Dimensions(mm)
Ball
dia
a
mis.
angle
Load ratings
(KN)
weight
Kg
H7
B C1 d1 d2 d3-6H h1 L3 (L4) L5 d4 d5 sw Dynamic Static
SPHS5 5 8 6 7.7 16 M5 27 11 35 4 9 11 9 11.11 13 2.5 6.6 0.016
SPHS6 6 9 6.75 8.9 18 M6 30 13 39 5 10 13 11 12.7 13 3.2 8.1 0.025
SPHS8 8 12 9 10.3 22 M8 36 16 47 5 12.5 16 14 15.87 14 5.4 12.6 0.043
SPHS10 10 14 10.5 12.9 26 M10 43 20 56 6.5 15 19 17 19.05 13 7.5 16.6 0.072
SPHS12 12 16 12 15.4 30 M12 50 23 65 6.5 17.5 22 19 22.22 13 10 22 0.107
SPHS14 14 19 13.5 16.8 34 M14 57 27 74 8 20 25 22 25.4 16 13 27.8 0.160
SPHS15 15 20 14 18.1 36 M14 61 30 79 8 21 26 22 26.98 16 14.5 29 0.186
SPHS16 16 21 15 19.3 38 M16 64 32 83 8 22 27 22 28.58 15 16 34.5 0.210
SPHS17 17 22 16 20.6 40 M16X1.5 67 34 87 10 24 31 27 30.16 14 18 36 0.259
SPHS18 18 23 16.5 21.8 42 M18X1.5 71 35 92 10 25 31 27 31.75 15 19.5 40.8 0.295
SPHS20 20 25 18 24.3 46 M20X1.5 77 39 100 10 27.5 34 30 34.92 14 23 46.5 0.380
SPHS22 22 28 20 25.8 50 M22x1.5 84 42 109 12 30 37 32 38.1 15 29 52.6 0.490
SPHS25 25 31 22 29.5 60 M24x2 94 48 124 12 33.5 42 36 42.86 15 40.5 74.1 0.750
SPHS28 28 35 24 32.29 66 M27x2 103 53 136 12 37 46 41 47.63 15 46.1 88.7 0.950
SPHS30 30 37 25 34.8 70 M30x2 110 56 145 15 40 50 41 50.8 17 54.3 94.0 1.130


Stainless Steel Rod Ends SCHS

SCHS30 Stainless Steel FISH EYE BEARING

Bearing No. Dimensions(mm)
Ball
dia
a0
mis.
angle
Load ratings
(KN)
weight
≈Kg
H7
B C1 d1 d2 d3-6H h1 L3 (L4) L5 d4 d5 sw Dynamic Static
SCHS5 5 8 6 7.7 18 M5 27 10 36 4 9 11 9 11.11 13 3.25 8 0.016
SCHS6 6 9 6.75 8.9 20 M6 30 13 40 5 10 13 11 12.7 13 4.25 8.9 0.022
SCHS8 8 12 9 10.3 24 M8 36 16 48 5 12.5 16 13 15.87 14 7.1 14.1 0.047
SCHS10 10 14 10.5 12.9 28 M10 43 20 57 6.5 15 19 17 19.05 13 9.8 19.3 0.077
SCHS12 12 16 12 15.4 32 M12 50 22 66 6.5 17.5 22 19 22.22 13 13.2 23.5 0.100
SCHS14 14 19 13.5 16.8 36 M14 57 25 75 8 20 25 22 25.4 16 17 28 0.160
SCHS16 16 21 15 19.3 42 M16 64 28 85 8 22 27 22 28.58 15 21.4 32 0.220
SCHS18 18 23 16.5 21.8 46 M18X1.5 71 32 94 10 25 31 27 31.75 15 26 42.5 0.320
SCHS20 20 25 18 24.3 50 M20X1.5 77 33 102 10 27.5 34 30 34.92 14 31 47.5 0.420
SCHS22 22 28 20 25.8 54 M22X1.5 84 37 111 12 30 37 32 38.1 15 42.2 57 0.540
SCHS25 25 31 22 29.5 60 M24x2 94 42 124 12 33.5 42 36 42.86 15 52.7 68 0.730
SCHS28 28 35 24 32.29 66 M27x2 103 44 136 12 37 46 41 47.63 15 58.8 79 0.949
SCHS30 30 37 25 34.8 70 M30x2 110 51 145 15 40 50 41 50.8 17 70.7 88 1.100


Stainless Steel Rod Ends SCOS

SCOS28 Stainless Steel rod end clevis

Bearing No. Dimensions(mm)
Ball
dia
a
mis.
angle
Load ratings
(KN)
weight
Kg
H7
B C1 d1 d2 d3-6g h L1 L2 Dynamic Static
SCOS5 5 8 6 7.7 18 M5 33 19 42 11.11 13 3.25 4.3 0.013
SCOS6 6 9 6.75 8.9 20 M6 36 21 46 12.7 13 4.25 6 0.020
SCOS8 8 12 9 10.3 24 M8 42 25 54 15.87 14 7.1 11 0.038
SCOS10 10 14 10.5 12.9 28 M10 48 28 62 19.05 13 9.8 17.4 0.055
SCOS12 12 16 12 15.4 32 M12 54 32 70 22.22 13 13.2 23.5 0.085
SCOS14 14 19 13.5 16.8 36 M14 60 36 78 25.4 16 17 28 0.140
SCOS16 16 21 15 19.3 42 M16 66 37 87 28.58 15 21.4 32 0.210
SCOS18 18 23 16.5 21.8 46 M18x1.5 72 41 95 31.75 15 26 42.5 0.280
SCOS20 20 25 18 24.3 50 M20X1.5 78 45 103 34.92 14 31 47.5 0.380
SCOS22 22 28 20 25.8 54 M22x1.5 84 48 111 38.1 15 42.2 57 0.480
SCOS25 25 31 22 29.5 60 M24x2 94 55 124 42.86 15 52.7 68 0.640
SCOS28 28 35 25 32.29 66 M27x2 103 62 136 47.63 15 58.8 79 0.949
SCOS30 30 37 25 34.8 70 M30x2 110 66 145 50.8 17 70.7 88 1.100


Stainless Steel Rod Ends SPHS..EC

Stainless Steel Rod Ends SPHS14EC


Bearing No. Dimensions(mm)
Ball
dia
a
mis.
angle
Load ratings
(KN)
weight
Kg
H7
B C1 d1 d2 d3-6H h1 L3 (L4) L5 d4 d5 sw Dynamic Static
SPHS5EC 5 8 6 7.7 16 M5 27 11 35 4 9 11 9 11.11 13 3.3 6.2 0.016
SPHS6EC 6 9 6.75 8.9 18 M6 30 13 39 5 10 13 11 12.7 13 4.7 7.8 0.025
SPHS8EC 8 12 9 10.3 22 M8 36 16 47 5 12.5 16 14 15.87 14 7.7 13.2 0.043
SPHS10EC 10 14 10.5 12.9 26 M10 43 20 56 6.5 15 19 17 19.05 13 10.4 17.3 0.072
SPHS12EC 12 16 12 15.4 30 M12 50 23 65 6.5 17.5 22 19 22.22 13 13.5 22.7 0.107
SPHS14EC 14 19 13.5 16.8 34 M14 57 27 74 8 20 25 22 25.4 16 17.2 28.2 0.160
SPHS16EC 16 21 15 19.3 38 M16 64 32 83 8 22 27 22 28.58 15 21 35.1 0.210
SPHS18EC 18 23 16.5 21.8 42 M18X1.5 71 35 92 10 25 31 27 31.75 15 25 43.2 0.295
SPHS20EC 20 25 18 24.3 46 M20x1.5 77 39 100 10 27.5 34 30 34.92 14 29.8 50.3 0.380
SPHS22EC 22 28 20 25.8 50 M22x1.5 84 42 109 12 30 37 32 38.1 15 36.2 63.9 0.490


Stainless Steel Rod Ends SPOS..EC

Stainless Steel Rod End Bearings SPOS20EC

Bearing No. Dimensions(mm)
Ball
dia
a
mis.
angle
Load ratings
(KN)
weight
Kg
H7
B C1 d1 d2 d3-6g h L1 L2 Dynamic Static
SPOS5EC 5 8 6 7.7 16 M5 33 20 41 11.11 13 3.3 4.8 0.012
SPOS6EC 6 9 6.75 8.9 18 M6 36 22 45 12.7 13 4.7 6.8 0.019
SPOS8EC 8 12 9 10.3 22 M8 42 25 53 15.87 14 7.7 12.3 0.032
SPOS10EC 10 14 10.5 12.9 26 M10 48 29 61 19.05 13 10.4 17.3 0.054
SPOS12EC 12 16 12 15.4 30 M12 54 33 69 22.22 13 13.5 22.7 0.085
SPOS14EC 14 19 13.5 16.8 34 M14 60 36 77 25.4 16 17.2 28.2 0.126
SPOS16EC 16 21 15 19.3 38 M16 66 40 85 28.58 15 21 35.1 0.185
SPOS18EC 18 23 16.5 21.8 42 M18X1.5 72 44 93 31.75 15 25 43.2 0.260
SPOS20EC 20 25 18 24.3 46 M20x1.5 78 47 101 34.92 14 29.8 50.3 0.340


Stainless Steel Rod Ends SPHSB..EC

Stainless Steel Rod Ends SPHSB12EC

Bearing No. Dimensions(mm)
Ball
dia
a°
mis.
angle
Load ratings
(KN)
weight
 kg
d +0.038
   -0.012
B C1 d1 d2
d3
UNF-2B
h1 L3 (L4) L5 d4 d5 sw
Dynamic
Cr
Static
Cor
SPHSB3EC 4.826 7.92 6.35 7.77 15.88 10-32 26.97 12.7 34.91 4.75 7.92 10.31 7.92 11.11 10 3.3 6.6 0.015
SPHSB4EC 6.35 9.53 7.14 9.02 19.05 1/4-28 33.32 17.45 42.85 4.75 9.52 11.89 9.52 12.7 13 4.8 11 0.025
SPHSB5EC 7.938 11.10 8.74 11.35 22.23 5/16-24 34.92 17.45 46.03 4.75 11.1 12.7 11.1 15.87 10 5.9 12 0.036
SPHSB6EC 9.525 12.7 10.31 13.13 25.4 3/8-24 41.28 20.62 53.98 6.35 14.27 17.45 14.27 18.26 9 8.2 18.2 0.061
SPHSB7EC 11.11 14.27 11.1 14.88 28.58 7/16-20 46.02 23.8 60.3 6.35 15.88 19.05 15.88 20.62 11 10 21.5 0.081
SPHSB8EC 12.7 15.88 12.7 17.73 33.32 1/2-20 53.98 26.97 70.64 6.35 19.05 22.22 19.05 23.8 9 15 30.6 0.133
SPHSB10EC 15.88 19.05 14.27 21.31 38.1 5/8-18 63.5 34.92 82.55 7.92 22.22 25.4 22.22 28.57 11 18 34.1 0.190
SPHSB12EC 19.05 22.23 17.45 24.84 44.45 3/4-16 73.03 39.67 95.25 7.92 25.4 28.58 25.4 33.33 10 27 47.9 0.285


Stainless Steel Rod Ends SPOSB..EC

SPOSB3EC Stainless Steel Rod End Bearings

Bearing No. Dimensions(mm)
Ball
dia
a°
mis.
angle
Load ratings
(KN)
weight
kg
d +0.038
  -0 012
B C1 d1 d2
d3
UNF-2A
h L1 L2 Dynamic Static
SPOSB3EC 4.826 7.92 6.35 7.77 15.88 10-32 31.75 19.05 39.69 11.11 10 2.8 4.4 0.013
SPOSB4EC 6.35 9.53 7.14 9.02 19.05 1/4-28 39.67 25.4 49.2 12.7 13 4.8 8.2 0.022
SPOSB5EC 7.938 11.10 8.74 11.35 22.23 5/16-24 47.63 31.75 58.75 15.87 10 5.9 13.1 0.037
SPOSB6EC 9.525 12.7 10.31 13.13 25.4 3/8-24 49.22 31.75 61.92 18.26 9 8.2 18.2 0.055
SPOSB7EC 11.11 14.27 11.1 14.88 28.58 7/16-20 53.98 34.93 68.28 20.62 11 10 21.5 0.078
SPOSB8EC 12.7 15.88 12.7 17.73 33.32 1/2-20 61.92 38.1 78.59 23.8 9 15 30.6 0.120
SPOSB10EC 15.88 19.05 14.27 21.31 38.1 5/8-18 66.68 41.28 85.73 28.57 11 18 34.1 0.180
SPOSB12EC 19.05 22.23 17.45 24.84 44.45 3/4-16 73.02 44.45 95.25 33.33 10 27 47.9 0.290


Stainless Steel Rod Ends SJF..T

Stainless Steel Rod Ends Precision Serie SJF4T

Bearing No. Dimensions(mm/inches)
Ball
dia
a°
mis.
angle
Load
ratings
(KN)
weight
 kg
d+0.038
   -0 012
B C1 d2
d3
UNF-2B
h1 l1 (l2) d4 SW
SJF4T 6.35 9.53 7.14 20.47 1/4-28 33.32 15.88 43.55 11.89 9.52 13.48 16 21.3 0.026
SJF4T 0.2500 0.375 0.281 0.806 1/4-28 1.312 0.625 1.714 0.468 0.375 0.531 16 21.3 0.026
SJF5T 7.938 11.11 8.74 22.86 5/16-24 34.93 17.45 46.35 12.7 11.1 15.06 14 26.3 0.041
SJF5T 0.3125 0.437 0.344 0.900 5/16-24 1.375 0.687 1.825 0.500 0.437 0.593 14 26.3 0.041
SJF6T 9.525 12.7 10.31 26.03 3/8-24 41.28 22.22 54.29 17.45 14.27 17.45 12 32.7 0.068
SJF6T 0.3750 0.500 0.406 1.025 3/8-24 1.625 0.875 2.13 0.687 0.562 0.687 12 32.7 0.068
SJF7T 11.112 14.27 11.1 29.21 7/16-20 46.02 25.4 60.6 19.05 15.88 19.83 14 35.2 0.089
SJF7T 0.4375 0.562 0.437 1.150 7/16-20 1.812 1.000 2.38 0.750 0.625 0.781 14 35.2 0.089
SJF8T 12.7 15.88 12.7 33.96 1/2-20 53.98 28.58 70.96 22.22 19.05 22.22 12 55.7 0.149
SJF8T 0.5000 0.625 0.500 1.337 1/2-20 2.125 1.125 2.97 0.875 0.750 0.875 12 55.7 0.149
SJF10T 15.875 19.05 17.27 38.74 5/8-18 63.5 34.93 82.87 25.4 22.22 26.97 16 61.6 0.216
SJF10T 0.6250 0.750 0.562 1.525 5/8-18 2.500 1.375 3.262 1.000 0.875 1.062 16 61.6 0.216
SJF12T 19.05 22.23 17.45 45.09 3/4-16 73.03 41.28 95.57 28.58 25.4 31.75 14 96.3 0.327
SJF12T 0.7500 0.875 0.687 1.775 3/4-16 2.875 1.625 3.762 1.125 1.000 1.250 14 96.3 0.327


Stainless Steel Rod Ends SJM..T

SJM7T Stainless Steel Rod Ends American Size

Bearing No.

Dimensions( inches)
Ball
dia
a
mis.
angle
Load
ratings
(ibs)
weight
  kg
+0.0000
  -0.0005
B +0.000
    - 0.002
C1+0.005
 - 0.005
d2 +0.010
   -0.010
d3
h -0.010
   -0.010
l1 +0.031
   -0.031
l2
SJM4T 0.2500 0.437 0.337 0.806 1/4-28 1.562 0.968 1.964 0.531 16 4874 0.032
SJM5T 0.3125 0.437 0.327 0.900 5/16-24 1.875 1.187 2.325 0.593 14 7196 0.039
SJM6T 0.3750 0.500 0.416 1.025 3/8-24 1.938 1.187 2.450 0.687 12 8580 0.061
SJM7T 0.4375 0.562 0.452 1.150 7/16-20 2.125 1.281 2.700 0.781 14 12000 0.083
SJM8T 0.5000 0.625 0.515 1.337 1/2-20 2.438 1.468 3.106 0.875 12 19520 0.126
SJM10T 0.6250 0.750 0.577 1.525 5/8-18 2.625 1.562 3.387 1.062 16 21920 0.192
SJM12T 0.7500 0.875 0.640 1.775 3/4-16 2.875 1.687 3.762 1.250 14 29310 0.289
Previous:
Next:
TKW Focuses On the Development and Manufacturing of General and Non-Standard Rolling bearings


Quick Links

Contact Us

 Yandian Industrial zone, Linqing City, Liaocheng,Shandong Province, China,
 +86-635-8509787 / +86-13280450757
 +86-13280450757
 +86-13280450757
Copyright © 2008-2021 TKW BEARINGS  Technical support :  leadong
