The toroidal roller bearing is a brand new radial roller bearing. This compact self-aligning roller bearing was launched in 1995. The bearing has a unique design that combines the self-aligning ability of spherical roller bearings with the unlimited axial displacement ability of cylindrical roller bearings. It can also have a smaller cross-sectional area, and needle roller bearings usually have this feature. Therefore, toroidal roller bearings are a good complement to spherical spherical roller bearings, cylindrical roller bearings and needle roller bearings. High load capacity, unlimited axial displacement and space saving can make it more and more widely used.
Various designs of toroidal roller bearings
(1) D≤>120mm reinforced polyamide 4.6
(2) 120<D≤600 mm, steel cage
(3) D>600 mm, brass cage
(4) The self-guided roller realizes the full complement CARB bearing
(5) The load carrying capacity of the dynamic bearing is increased by about 30%
(6) Reduced speed limit
(7) Sealed full roller bearings for use in polluted environments
(8) No maintenance required, sealed for life
(9) Low rotation or vibration
Toroidal roller bearing features
(1) Compact design
(2) The unique internal geometric structure of the toroidal bearing can ensure the uniform distribution of the load between the roller and the raceway and the axial displacement
(3) The axial displacement in the toroidal bearing is about ±10% of the bearing width
(4) The load between the roller and the raceway can always be evenly distributed, so as to achieve the best operating conditions and alignment errors
(5) The toroidal bearing can allow shaft eccentricity/alignment error not exceeding 0.50
(6) Will not reduce life or increase friction
(7) Even load distribution
Advantages of toroidal roller bearings:
Toroidal roller bearings can allow axial displacement without causing additional axial force or friction. Therefore, the loads in the new bearing system are only external radial and axial forces.
The new bearing system provides customers with the following advantages:
(1) Lower bearing load
(2) The bearing distribution is improved
(3) Extended relubrication interval
(4) Downsizing becomes possible
(5) The service life of bearings and lubricants are significantly extended
Application range of EASIER toroidal roller bearings:
(1) Paper machine
(2) Continuous casting machine
(3) Stone crusher
(4) Grinding machine
(5) Industrial transmission
(6) Conveyor belt
(7) Textile machine
